| CPU | Intel® Xeon® Scalable processor (TDP 最大支持270W) |
| 系統內存 | 6 x 288-pin DDR4-3200 RDIMM, 最大支持 384GB |
| 6 x 288-pin DDR4-3200 LRDIMM, 最大支持 384GB |
| 芯片組 | Intel® C621A |
| BIOS | AMI |
| SSD | M.2 key M 2280 with PCIe x4 signal |
| 看門狗定時器 | 1~255 秒可編程設置 |
| 擴展接口 | 2 x PCIe x16 slot (signal Gen 4) |
| 1 x PCIe x16 slot (signal: x16 or x8) |
| 1 x PCIe x8 slot (signal: x0 or x8) |
| 2 x PCIe x8 slot |
| 尺寸 | 305 x 244 mm ATX母板 |
| 板厚 | 1.6 mm |
| 工作溫度 | 0°C to +60°C (+32°F to +140°F) |
| 相對濕度 | 10% to 95% 相對濕度，無冷凝 |
| SATA | 6 x SATA-600 with RAID 0/1/5/10 |
| 硬件監控 | 檢測 CPU/系統溫度, 電壓，支持智能風扇控制 |
| 以太網 | 2 x 10/100/1000 Mbps以太網 (Intel® i210-AT) |
| 音頻 | 高清音頻解碼 MIC-in/Line-in/Line-out with audio kit AX93242 (可選) |
| USB | 4 x USB 3.1 Gen1 (rear I/O) |
| 2 x USB 3.1 Gen1 (internal box header) 6 x USB 2.0 (internal box header) |
| 1 x USB 2.0 (180D TypeA) |
| 串口 | 1 x RS-232/422/485 (rear I/O) |
| PS/2 Combo 接口 | 1 x PS/2 keyboard and mouse |
| TPM | TPM 2.0 module (可選) |
| SMBus | Yes |
| Digital I/O | 8-位可編程 |
| 圖形控制器 | AST2510 |
| 顯存容量 | N/A |
| 顯示接口 | 1 x VGA |
